Class D Metal Fire Stored Pressure

Suitable for Class D fire that is involving Combustible metals like magnesium, sodium, Potassium etc.

TECHNICAL SPECIFICATIONS

SpecificationDCP 4 KGDCP 6 KGDCP 9 KG
BIS SpecificationIS 15683:2018IS 15683:2018IS 15683:2018
Type of FireDDD
Extinguisher TypeStored Pressure / Gas CartridgeStored Pressure / Gas CartridgeStored Pressure / Gas Cartridge
Extinguishing MediaDry Powder (Sodium Bi‑carbonate)Dry Powder (Sodium Bi‑carbonate)Dry Powder (Sodium Bi‑carbonate)
Min. Effective Discharge (%)909090
Min Jet Length (mtr)466
Test Pressure (kgf/cm²)353535
Charged Pressure (kgf/cm²)151515
Operation PositionUprightUprightUpright
Operating ValveSqueeze Grip Type with Discharge Pipe & NozzleSqueeze Grip Type with Discharge Pipe & NozzleSqueeze Grip Type with Discharge Pipe & Nozzle
Operating Temperature-30° to +60°C-30° to +60°C-30° to +60°C
Fire Rating21B34B55B
